Available Options
A1200 Insulation Layer:

A1200 LED Adapter:

Addon 9-pin port board:

CPU Boost Kit:

Floppy Drive Accessories:

Hard Drive (Micro SD):

Mouse:

Vented Trapdoor:

A1200NG motherboard revision 3A

The A1200NG motherboard fits into original Commodore 1200, Escom 1200 and reproduction desktop cases. The ports align with the holes in the case using the supplied backplate.

AmiBench is the desktop pre-installed with many famous classic applications such as Final Writer, OctaMED, Directory Opus, HippoPlayer, YAM and AmiBrowser modern web browser. Create your own boot system: A1200NG supports installing of multiple operating systems with the corresponding ROMs. You can boot directly into any of the OS you have installed on the system.

Features:

Games menu: add, edit & launch ADF/HDF/WHDBoot games, scene demos & apps (OCS, ECS, AGA).

AmiBench: 1080p screenmode with 32-bit icon set. Run Classic 68k programs.

Dual 9-pin Joystick Ports: accepts Commodore compatible joysticks ¹

HDMI compatible 1080p output: plugs into HDMI compatible television or monitor

Wireless Internet: connects to AmiSphere for system updates and email

Bluetooth: optionally output audio to Bluetooth speaker

34-pin Floppy Header: read and write to real 880K floppy disks (Greaseweazle compatible)

RS232 Serial Port (DB25)

System RAM: 4GB in total. 1GB Fast Memory allocated for AmiBench.

Hard Drive: 64GB, 128GB or 256GB (High Speed) option.

Internal USB headers for connection of optional USB to SATA or USB to IDE adapters.

External USB headers for connection of DrawBridge USB floppy disk drives, Mice, MIDI interfaces, Flash Drives.

Pre Installed Software:

AmiBench Release V46

Personal Paint (PPaint) V7.4

OctaMED V8

Directory Opus V4

Final Writer V7.2

YAM email client

JST

AmiBrowser
modern web browser

Utilities: EaglePlayer, HippoPlayer, Dock, Clock, Calendar, UnArchiver, PlayMP3, PlayVideo

Games: Super Skidmarks, Thunderhell, Virtual GP, T-Racer

What is included?

A1200NG motherboard

ARM module (H618 Quad Core 1.5Ghz/4GB RAM)

64GB or 128GB or 256GB micro SD card

HDMI cable with backplate (fits underneath floppy drive)

Metal backplate for ports

Power Supply Unit

Printed Colour Manual

A1200NG case badge

Silver foil serial case sticker

Hex bolts and screws

Product options:

A1200 9-pin joystick port 1 board

A1200 Triple LED adapter module

A1200 motherboard insulation layer

CPU Boost Kit

Rear External Ports:

9-pin Joystick

USB ports

25-pin Serial Port

Left / Right Audio RCA audio out

Composite (no driver support)

Power In Port

Compact Flash reader

Internal Connectors:

34-pin Floppy Disk Drive header

USB header (dual)

A1200 LED module header

A1200 keyboard ribbon header (31 pin)

4-pin Power header for optional floppy disk drive

4-pin Power header for optional SATA/IDE hard drive

2-pin Fan header

Speed Performance
The A1200NG delivers the following SysInfo speed rating of 257 MIPs or 303 MIPs in with the optional CPU Boost Kit installed and activated.

Floppy Disk Drive Compatibility
The A1200NG is compatible with the following floppy disk drives (not supplied):

PC compatible 1.44MB drive

Commodore original 880K / 1.76MB drive drive

It is recommended to use original 600 / 1200 floppy disk drives to fit into an original case.

¹ single 9-pin joystick port is available on motherboard and a second 9-pin joystick port is attached using a plug in board (product option).

The A1200NG is available for ordering. We are pleased to confirm that delivery of the pre-orders has started in April and continues in September 2025. Due to it's popularity, please allow extra time for assembly and fulfillment of this product.

The A1200 official brand website is A1200.com. A1200 is a registered trademark of AmigaKit Ltd in the United Kingdom, Belgium, Netherlands, Luxembourg, Spain and Australia. The A1200 NG and A1200 NG are trademarks of AmigaKit Ltd. Double tick is a trademark used under licence.
